STECS Throttle System - Max

STECS Throttle System - Max

Based on a solid steel platform, the STECS Max can be used as a desktop stand-alone device, or mounted to a sim rig. Includes MFH (MultiFunctional Holder) compatible fixture and one MFH to connect frontal extension modules.

For the perfect and most ergonomical desk mounting option, please see the UCM-S STECS Max .

Includes

• 1 STECS base
• 1 MTG-L grip

• 1 MTG-R grip
• Red rubber grip pads (pre-installed)
• Green and gray rubber pads included

• 5 Detent Frames

• 4 L-shape detent - regular

• 4 L-shape detent - large

• 5 V-shape detent - regular

• 5 V-shape detent - large

• 2 W-shape

• 1 ATEM Module
• 1 STEM Module (to be installed on the MFH at the front of the throttle)

• 1 MFH

• 1 STECS Accessory Magazine
• 1 Phillips head screwdriver
• 1 Hex screwdriver
• 1 USB cable (180 cm / 6')

STECS Throttle Grips

MTG-L (Modern Throttle Grip Left)

• 2 Buttons

• 2 Triggers

• 2 Wheel encoders

MTG-R (Modern Throttle Grip Right)

• 2 Triggers
• 1 Analog Ministick

• 1 Analog Wheel Axis
• Pre-configured Button Modules:
• 2x Buttons, 1x 3-pos Hat, 2x 5-pos Hats
• Additional Button Modules included:
• 3x Buttons, 3x 5-pos Hats, 3x replaceable Hat caps

ATEM Module

• 4 Buttons
• 2 Safety lid protected button
• 1 Multifunctional 4-position encoder with a central push button

STEM Module

• 8 Buttons
• 2 K-switches with central push button
• 2 Encoder with central push button
• 1 Self-centering 3-position flip switch
• 1 3-position flip switch

STECS Base

• 2 Analog Axes

• 4 Ball bearings on main axes
• 2 Buttons
• 1 5-position rotary switch


General Specifications

• Grips and base made from industrial-grade ABS
• Base supported with glass-fiber-reinforced PA for load-bearing structures

• Tabletop baseplate made from steel
• 32-bit ARM Controllers inside the base and grip
• ALPS buttons (Japan OEM) for extended longevity
• Contactless MaRS sensors with High Resolution
• Firmware Upgrade via USB
• Onboard Memory for Storing Profiles
